New original Sick inductive Proximity Sensor IMB12-04BNSVW5S With Best Price
| Plaats van herkomst | Duitsland |
|---|---|
| Merknaam | Sick |
| Certificering | - |
| Modelnummer | IMB12-04BNSVW5S |
| Min. bestelaantal | 1 |
| Prijs | USD20/PC |
| Verpakking Details | Origineel |
| Levertijd | 2 weken |
| Betalingscondities | L/C, D/A, D/P, T/T, Western Union |
| Levering vermogen | Kindertype |
Productdetails
| garantie | 1 jaar | Beschermingsklasse behuizing | IP68 |
|---|---|---|---|
| Restgolf | ≤ 10 % | elektromagnetische compatibiliteit | Volgens EN 60947-5-2 |
Productomschrijving
Mechanical/Electronic Parameters
Power supply voltage: 10 V DC ... 30 V DC
Residual ripple ≤ 10%
Voltage drop ≤ 2 V 1)
Hysteresis 3 % ... 20%
Reproducibility
≤ 2 % 2)
3)
Temperature drift (Sr) ± 10 %
Electromagnetic compatibility Compliant with EN 60947-5-2
Continuous current Ia ≤ 200 mA
No-load current ≤ 10 mA
Conductor material PVC
Conductor cross-sectional area 0.25 mm²
Conductor diameter Ø 3.9 mm
Short-circuit protection ✔
Power-on pulse protection ✔
Impact and vibration resistance 100 g / 2 ms / 500 cycles; 150 g / 1 million cycles; 10 Hz ... 55 Hz / 1 mm; 55 Hz ... 500 Hz / 60 g
Operating environment temperature: -25 ℃ ... +75 ℃
Shell material: Stainless steel V2A, DIN 1.4305 / AISI 303
Material for the sensing surface: Plastic, LCP
Shell length: 50 mm
Available screw thread length: 46 mm
Maximum tightening torque: Typ. 20 Nm 4)
Typ. 32 Nm 5)
Protection level: III
UL document number: E181493
1) At Ia max.
2) The working voltage UB and the ambient temperature Ta remain constant.
3) From Sr.
4) Use on the non-threaded surface of the nut.
5) Use on the threaded surface of the nut.
Reduction factor
Note: These data are for reference only and may have some deviations.
Steel St37 (Fe) 1
Stainless Steel (V2A) Approximately 0.65
Aluminum (Al) Approximately 0.35
Copper (Cu) Approximately 0.24
Brass (Ms) Approximately 0.38 Installation Guide
Note: For related diagrams, please refer to "Installation Instructions". B 12 mm
C 12 mm
D 12 mm
F 32 mm
Certificate
EU declaration of conformity ✔
UK declaration of conformity ✔
ACMA declaration of conformity ✔
Moroccan declaration of conformity ✔
China-RoHS ✔
cULus Certification ✔
